| Description | FEATURES:
- DSP Technology for fast & smooth charging
- Auto sense intelligent charging (ASIC) adjustment
- Highly robust & reliable Ideal for computer
- Generator Compatible
- Wide charging voltage range
- User selectable charging current
- Compact design
- Input range 180VAC to 265VAC UPS Mode
- Input range 100VAC to 280VAC Normal Mode
- DC Voltage - 48V
- Charge current <15 A
| Mercury 1.5KVA Solar Hybrid Inverter MPPT 12V Complete Inverter System. Engineered with cutting-edge technology and advanced features, this inverter system is your go-to solution for all your solar energy needs. |
- A smart battery charger that optimizes battery performance
- Selectable charging current depending on the applications
- Selectable input voltage range
- Configurable solar/AC input priority
- Auto restart while AC recovers
- A perfect alarming system
| | PRAG 10KVA 48V INVERTER features power factor correction, sophisticated multi-stage charging and pure sine wave output with superior surge capability to meet demanding power needs of inductive loads without endangering the equipment. This series is equipped with a powerful charger of up to110Amps (depending on model). The overload capacity is 300% of continuous output for up to 20 seconds to reliably support sudden increase in loads without damaging the system within the time frame. | PRAG 4KVA-48V H-Series (Pure Sine Wave) Inverter / Charger is a combination of an inverter, battery charger and AC auto-transfer switch that forms one complete system with a peak conversion efficiency rating of 88%. Packed with powerful features, it is simply one of the most reliable and robust inverter/chargers in the market today.
PRAG 4KVA-48V H-Series features power factor correction, sophisticated multi-stage charging and pure sine wave output with superior surge capability to meet demanding power needs of inductive loads without endangering the equipment. This series is equipped with a powerful charger of up to110Amps (depending on model). The overload capacity is 300% of continuous output for up to 20 seconds to reliably support sudden increase in loads without damaging the system within the time frame. |
| Content | | Mercury 1.5KVA Solar Hybrid Inverter MPPT 12V Complete Inverter System. Engineered with cutting-edge technology and advanced features, this inverter system is your go-to solution for all your solar energy needs.
Key Features and Benefits
- Maximum Power Point Tracking (MPPT): This technology optimizes your solar panel’s output, enhancing your system’s overall efficiency.
- Automatic Switch-Over Function: Experience uninterrupted power supply with the auto switch-over feature that toggles between solar and grid power sources during power outages.
- User-Friendly LCD Display: Real-time system performance and status are displayed, ensuring you’re always in the know.
- Safety First: Equipped with multiple safety features to protect your appliances and give you peace of mind.
- High-Quality Mercury Deep Cycle GEL Batteries: Comes with a Mercury Deep Cycle GEL battery that guarantees optimal performance and reliability.
- Expert Installation and After-Sales Support: Our professional team will handle the installation and offer prompt after-sales support.
- 7-Day Money-Back Guarantee and 12-Month Warranty: Your investment is safe with us. If you’re not satisfied, you can return the product within 7 days for a full refund.
- Eco-Friendly and Cost-Effective: Reduce your carbon footprint and save on energy bills with this efficient inverter system.
|
| Brand |
iPower |
| Warranty Period |
1 Year |
| MODEL |
iPowerxMaX3000-24 |
| RatedPower |
3000VA/3000W |
| INPUT |
| Voltage |
230VAC |
| SelectableVoltageRange |
170-280VAC(ForPersonalComputers);Â 90-
280 VAC(ForHomeAppliances) |
| FrequencyRange |
50Hz/60Hz(Autosensing) |
| OUTPUT |
| ACVoltageRegulation(Batt.Mode) |
230VAC±5% |
| SurgePower |
6000VA |
| Efficiency(Peak) |
90%~93% |
| TransferTime |
10ms(ForPersonalComputers);20ms(For
HomeAppliances) |
| Waveform |
Puresinewave |
| BATTERY |
| BatteryVoltage |
24VDC |
| FloatingChargeVoltage |
27VDC |
| OverchargeProtection |
32VDC |
| SOLARCHARGER&ACCHARGER |
| SolarChargerType |
MPPT |
| MaximumPVArrayOpenCircuitVoltage |
450VDC |
| MaximumPVArrayPower |
3000W |
| MPPRange@OperatingVoltage |
60-400VDC |
| MaximumSolarChargeCurrent |
80A |
| MaximumACÂ ChargeCurrent |
80A |
| MaximumChargeCurrent |
80A |
| PHYSICAL |
| Dimension,DxWxH(mm) |
100x288x390 |
| NetWeight(kgs) |
8.0 |
| CommunicationInterface |
RS232 |
| ENVIRONMENT |
| Humidity |
5%to95%RelativeHumidity(Non-
condensing) |
| OperatingTemperature |
-10°Cto50°C |
| StorageTemperature |
-15°Cto60°C |
| iPower Infiniti 5KVA/48V Inverter PV Array:9000W iPowerPlus Inverters are digital smart power solutions which range from 1KVA-20KVA. The Pure Sine Wave Hybrid Inverter comes with an in-built solar charge controller that connects automatically to solar and utility supply. This allows you to switch between AC Power and Solar Power
- Rated Output Power 5000VA/4000W
- Maximum PV Array Power 9000W
- MPPT Voltage Range 60-115 VDC
- Dimension 194 x 295 x 455
- Weight 17kg
- Maximum Charging Current 140
| PRAGÂ 10KVA 48V INVERTER W-EYÂ (Pure Sine Wave) Inverter / Charger is a combination of an inverter, battery charger and AC auto-transfer switch that forms one complete system with a peak conversion efficiency rating of 88%. Packed with powerful features, it is simply one of the most reliable and robust inverter/chargers in the market today.
PRAG 10KVA 48V INVERTER features power factor correction, sophisticated multi-stage charging and pure sine wave output with superior surge capability to meet demanding power needs of inductive loads without endangering the equipment. This series is equipped with a powerful charger of up to110Amps (depending on model). The overload capacity is 300% of continuous output for up to 20 seconds to reliably support sudden increase in loads without damaging the system within the time frame.
PRAGÂ 10KVA 48V INVERTERÂ Features
- Powerful Pure Sine Wave (PSW) Inverter/Charger
- 13 Vdc inverter Battery Recover Point (BRP) – Dedicated for Renewable Energy Systems
- High efficiency design and Power Saving Mode to conserve energy
- 8 Pre-set battery type selectors with de-sulphation for totally flat inverter batteries
- 4 Step Intelligent Battery Charging system, and Power Factor Correction (PFC)
- 8 Ms typical transfer time between utility and battery bank. This guarantees power continuity and consistency
- 15 Seconds delay before transfer when AC Resumes, and protection for load when used with generator
- Battery DOD (Depth of Discharge) setting from 50%
- Easy and straightforward installation
- Designed to operate under harsh environment
- DC Start and Automatic Self Diagnostic (ASD) function
- Compatible with Linear and Non-Linear loads
- Low DC Voltage home and office appliances support
- Up to 120Amp charging current selectable from 0%-100%
- Battery priority mode for preferred UPS configuration
| Inverter Output |
| Model |
PT-INV-10KVA/9000W 48V-Color LED, Wall-H |
| Continuous Output Power |
9000W |
| Surge Rating(20s) |
24000W |
| Capable of Starting Electric Motor |
8HP |
| Output Waveform |
Pure Sine wave/Same as input(Bypass mode) |
| Nominal Efficiency |
>88%(Peak) |
| Line Mode Efficiency |
>95% |
| Power Factor |
0.9-1.0 |
| Nominal Output Voltage rms |
 220-230-240Vac |
| Output Voltage Regulation |
±10% RMS |
| Output Frequency |
50± 0.3Hz/60± 0.3Hz |
| Short Circuit Protection |
Yes, Current Limit Function (Fault after 1sec) |
| Typical transfer Time |
10ms(Max) |
| THD |
< 10% |
| DC Input |
| Nominal Input Voltage |
12.0Vdc |
| ( *2 for 24Vdc, *4 for 48Vdc) |
| Minimum Start Voltage |
10.0Vdc/10.5Vdc ( *2 for 24Vdc, *4 for 48Vdc) |
| Low Battery Alarm |
10.5Vdc/11.0Vdc ( *2 for 24Vdc, *4 for 48Vdc) |
| Low Battery Trip |
10.0Vdc/10.5Vdc ( *2 for 24Vdc, *4 for 48Vdc) |
| High Voltage Alarm & Fault |
16.0Vdc ( *2 for 24Vdc, *4 for 48Vdc) |
| High DC Input Recovery |
15.5Vdc |
| Low Battery voltage recover |
15.5Vdc ( *2 for 24Vdc, *4 for 48Vdc) |
| Idle Consumption-Search Mode |
< 25 W when Power Saver On |
| Charge |
| Input Voltage Range |
Wide: 90~135VAC / 164~243VAC
Narraw: 100~135VAC / 194~243VAC |
| Input Frequency Range |
Narrow: 47-55±0.3Hz for 50Hz, 57-65±0.3Hz for 60Hz Wide:43±0.3Hz plus for 50Hz/60Hz |
| Output Voltage |
Depends on battery type |
| Charger Breaker Rating |
40A |
| Max Charge Rate |
50Â +Â 5A/30Â +Â 5A (* 50A for 24V and 30A for 48V) |
| Over Charge Protection Shutdown |
15.7V for 12Vdc ( *2 for 24Vdc, *4 for 48Vdc) |
| Charger curve(4 stage constant current)
4 step digital controlled progressive charge |
Battery types ( *2 for 24Vdc, *4 for 48Vdc) |
| Battery type |
Float Vdc |
| Gel U.S.A |
13.7 |
| A.G.M 1 |
13.4 |
| A.G.M 2 |
13.7 |
| Sealed Lead Acid |
13.6 |
| Gel Euro |
13.8 |
| Open Lead Acid |
13.3 |
| Calcium |
13.6 |
| De-sulphation |
15.5 for 4hrs |
| Remote Control |
Yes. Optional |
| Bypass & Protection |
| Input Voltage Waveform |
Sine wave (Grid or Generator) |
| Nominal Voltage |
220Vac |
| Low Voltage Trip |
184V/140V±4% |
| Low Voltage re engage |
194V/150V±4% |
| High Voltage Trip |
253V/270V±4% |
| High Voltage re engage |
243V/260V±4% |
| Max Input AC Voltage |
280VAC |
| Nominal Input Frequency |
50Hz or 60Hz (Auto detect) |
| Low Freq Trip |
Narrow: 47±0.3Hz for 50Hz, 57±0.3Hz for 60Hz
Wide:40±0.3Hz for 50Hz/60Hz |
| Low Freq re engage |
Narrow: 48±0.3Hz for 50Hz, 58±0.3Hz for 60Hz
Wide:42±0.3Hz for 50Hz/60Hz |
| High Freq Trip |
Narrow: 55±0.3Hz for 50Hz, 65±0.3Hz for 60Hz
Wide: 70±0.3Hz for 50Hz/60Hz |
| High Freq re engage |
Narrow: 54±0.3Hz for 50Hz, 64±0.3Hz for 60Hz
Wide: 68±0.3Hz for 50Hz/60Hz |
| Output Short circuit protection |
Circuit breaker |
| Bypass breaker rating |
63A |
| Transfer switch rating |
80amp for UL |
| Max bypass current |
80amp |
| Mechanical Specification |
| Mounting |
Wall mount |
| Inverter Dimensions(L*W*H) |
588*415*200mm |
| Inverter Weight |
66KG |
| Shipping Dimensions(L*W*H) |
750x520x310mm |
| Shipping Weight |
68KG |
| Display |
Status LEDs / Status LEDs+LCD |
| Standard Warranty |
1 Year |
| PRAG 4KVA-48V H-Series (Pure Sine Wave) Inverter / Charger is a combination of an inverter, battery charger and AC auto-transfer switch that forms one complete system with a peak conversion efficiency rating of 88%. Packed with powerful features, it is simply one of the most reliable and robust inverter/chargers in the market today.
PRAG 4KVA-48V H-Series features power factor correction, sophisticated multi-stage charging and pure sine wave output with superior surge capability to meet demanding power needs of inductive loads without endangering the equipment. This series is equipped with a powerful charger of up to110Amps (depending on model). The overload capacity is 300% of continuous output for up to 20 seconds to reliably support sudden increase in loads without damaging the system within the time frame.
PRAG 4KVA – 48V Inverter Features
- Powerful Pure Sine Wave (PSW) Inverter/Charger
- 13 Vdc inverter Battery Recover Point (BRP) – Dedicated for Renewable Energy Systems
- High efficiency design and Power Saving Mode to conserve energy
- 8 Pre-set battery type selectors with de-sulphation for totally flat inverter batteries
- 4 Step Intelligent Battery Charging system, and Power Factor Correction (PFC)
- 8 Ms typical transfer time between utility and battery bank. This guarantees power continuity and consistency
- 15 Seconds delay before transfer when AC Resumes, and protection for load when used with generator
- Battery DOD (Depth of Discharge) setting from 50%
- Easy and straightforward installation
- Designed to operate under harsh environment
- DC Start and Automatic Self Diagnostic (ASD) function
- Compatible with Linear and Non-Linear loads
- Low DC Voltage home and office appliances support
- Up to 120Amp charging current selectable from 0%-100%
- Battery priority mode for preferred UPS configuration
| Inverter Output |
| Model |
PT-INV-4KVA 48V-Color LED, Wall-H |
| Continuous Output Power |
3000W |
| Surge Rating(20s) |
9000W |
| Capable of Starting Electric Motor |
3HP |
| Output Waveform |
Pure Sine wave/Same as input(Bypass mode) |
| Nominal Efficiency |
>88%(Peak) |
| Line Mode Efficiency |
>95% |
| Power Factor |
0.9-1.0 |
| Nominal Output Voltage rms |
220-230-240Vac |
| Output Voltage Regulation |
±10% RMS |
| Output Frequency |
50Hz ± 0.3Hz |
| Short Circuit Protection |
Yes, Current Limit Function (Fault after 1sec) |
| Typical transfer Time |
10ms(Max) |
| THD |
< 10% |
| DC Input |
| Nominal Input Voltage |
12.0Vdc |
| ( *2 for 24Vdc, *4 for 48Vdc) |
| Minimum Start Voltage |
10.0Vdc/10.5Vdc ( *2 for 24Vdc, *4 for 48Vdc) |
| Low Battery Alarm |
10.5Vdc/11.0Vdc ( *2 for 24Vdc, *4 for 48Vdc) |
| Low Battery Trip |
10.0Vdc/10.5Vdc ( *2 for 24Vdc, *4 for 48Vdc) |
| High Voltage Alarm & Fault |
16.0Vdc ( *2 for 24Vdc, *4 for 48Vdc) |
| High DC Input Recovery |
15.5Vdc |
| Low Battery voltage recover |
15.5Vdc ( *2 for 24Vdc, *4 for 48Vdc) |
| Idle Consumption-Search Mode |
< 25 W when Power Saver On |
| Charge |
| Input Voltage Range |
Wide: 90~135VAC / 164~243VAC
Narraw: 100~135VAC / 194~243VAC |
| Input Frequency Range |
Narrow: 47-55±0.3Hz for 50Hz, 57-65±0.3Hz for 60Hz | Wide:43±0.3Hz plus for 50Hz/60Hz |
| Output Voltage |
Depends on battery type |
| Charger Breaker Rating |
20A |
| Max Charge Rate |
50Â +Â 5A/30Â +Â 5A (* 50A for 24V and 30A for 48V) |
| Over Charge Protection Shutdown |
15.7V for 12Vdc ( *2 for 24Vdc, *4 for 48Vdc) |
| Charger curve(4 stage constant current)
4 step digital controlled progressive charge |
Battery types ( *2 for 24Vdc, *4 for 48Vdc) |
| Battery type |
Fast Vdc |
| Gel U.S.A |
13.7 |
| A.G.M 1 |
13.4 |
| A.G.M 2 |
13.7 |
| Sealed Lead Acid |
13.6 |
| Gel Euro |
13.8 |
| Open Lead Acid |
13.3 |
| Calcium |
13.6 |
| De-sulphation |
15.5 for 4hrs |
| Remote Control |
Yes. Optional |
| Bypass & Protection |
| Input Voltage Waveform |
Sine wave (Grid or Generator) |
| Nominal Voltage |
120Vac |
| Low Voltage Trip |
184V/140V±4% |
| Low Voltage re engage |
194V/150V±4% |
| High Voltage Trip |
253V/270V±4% |
| High Voltage re engage |
243V/260V±4% |
| Max Input AC Voltage |
280VAC |
| Nominal Input Frequency |
50Hz or 60Hz (Auto detect) |
| Low Freq Trip |
Narrow: 47±0.3Hz for 50Hz, 57±0.3Hz for 60Hz
Wide:40±0.3Hz for 50Hz/60Hz |
| Low Freq re engage |
Narrow: 48±0.3Hz for 50Hz, 58±0.3Hz for 60Hz
Wide:42±0.3Hz for 50Hz/60Hz |
| High Freq Trip |
Narrow: 55±0.3Hz for 50Hz, 65±0.3Hz for 60Hz
Wide: 70±0.3Hz for 50Hz/60Hz |
| High Freq re engage |
Narrow: 54±0.3Hz for 50Hz, 64±0.3Hz for 60Hz
Wide: 68±0.3Hz for 50Hz/60Hz |
| Output Short circuit protection |
Circuit breaker |
| Bypass breaker rating |
30A |
| Transfer switch rating |
30amp for UL |
| Max bypass current |
30amp |
| Mechanical Specification |
| Mounting |
Wall mount |
| Inverter Dimensions(L*W*H) |
388*3415*200mm |
| Inverter Weight |
27KG |
| Shipping Dimensions(L*W*H) |
550x320x310mm |
| Shipping Weight |
29KG |
| Display |
Status LEDs / Status LEDs+LCD |
| Standard Warranty |
1 Year |
|
Rating & Review
There are no reviews yet.
